FUNAI LCD-A2006 - Page 46

20060619 13-2 L4620EL
! ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C641! SAFETY CAP. 2200pF/250V KX CA2E222MR050
C643 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C645 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C646 FILM CAP.(P) 0.082µF/50V J or CMA1JJS00823
FILM CAP.(P) 0.082µF/50V J or CA1J823MS029
POLYESTER FILM CAP. (PB FREE) 0.082µF/
100V J
CA2A823DT018
C647 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C648 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C649 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M or CA1A471SP085
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTM471
C650 ELECTROLYTIC CAP. 330µF/25V M or CE1EMASDL331
ELECTROLYTIC CAP. 330µF/25V M or CA1E331SP085
ALUMINUM ELECTROLYTIC CAP 330µF/25V M CE1EMASTM331
C651 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/6.3V H7 CE0KMAVSM470
C652 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100
C653 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M or CA1A471SP085
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTM471
C654 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C655 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M or CA0K471SP085
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C656 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C657 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C659 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J or CA1J223MS029
POLYESTER FILM CAP. (PB FREE) 0.022µF/
100V J
CA2A223DT018
C660 FILM CAP.(P) 0.0068µF/50V J or CMA1JJS00682
FILM CAP.(P) 0.0068µF/50V J or CA1J682MS029
POLYESTER FILM CAP. (PB FREE) 0.0068µF/
100V J
CA2A682DT018
C663 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C664 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C702 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C703 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C707 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C710 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C711 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C712 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C713 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C714 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C715 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C716 CERAMIC CAP.(AX) CH J 560pF/50V CCK1JJTCH561
C717 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C718 CERAMIC CAP.(AX) CH J 560pF/50V CCK1JJTCH561
C719 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C720 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C721 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C722 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C723 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C730 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C742 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
Ref. No. Description Part No.
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C743 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C745 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C746 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C747 ELECTROLYTIC CAP. 33µF/16V M H7 or CE1CMAVSL330
ALUMINUM ELECTROLYTIC CAP 33µF/16V H7 CE1CMAVSM330
C751 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C753 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C756 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C758 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C761 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/6.3V H7 CE0KMAVSM101
C762 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C766 ELECTROLYTIC CAP. 100µF/16V M H7 or CE1CMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/16V H7 CE1CMAVSM101
C767 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C768 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C781 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C782 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C783 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100
C784 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C785 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C787 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C791 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C792 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/6.3V H7 CE0KMAVSM101
C801 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C802 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C810 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C811 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M or CA1C101SP085
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101
C812 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C813 PCB JUMPER D0.6-P5.0 JW5.0T
C814 PCB JUMPER D0.6-P5.0 JW5.0T
C815 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C818 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C819 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C820 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C831 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C832 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C833 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C834 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C835 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C836 CHIP CERAMIC CAP. CH D 3pF/50V or CHD1JD3CH3R0
CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
Ref. No. Description Part No.
