FUNAI LCD-A2006 - Page 52

20060619 13-8 L4620EL
FUNCTION CBA
IR SENSOR CBA
INVERTER CBA
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITOR
C33 CERAMIC CAP.(AX) F Z 0.01µF/25V CCA1EZTFZ103
CONNECTOR
CN31B WIRE ASSEMBLY 5PIN 5PIN 110MM AWG26 WX1L4620-001
RESISTORS
R24 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R25 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R26 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R27 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R28 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R29 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002
R30 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R31 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R32 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R33 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
SWITCHES
SW30 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW31 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW32 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW33 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW34 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW36 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW37 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C53 ELECTROLYTIC CAP. 47µF/10V M or CE1AMASDL470
ELECTROLYTIC CAP. 47µF/10V M or CA1A470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/10V M CE1AMASTM470
DIODE
D51 LED L-53HT NP4Z000L53HT
RESISTORS
R63 CHIP RES. 1/10W J 68 Ω or RRXAJR5Z0680
RES CHIP 1608 1/10W J 68 Ω RRXA680YF002
R64 CHIP RES. 1/10W J 68 Ω or RRXAJR5Z0680
RES CHIP 1608 1/10W J 68 Ω RRXA680YF002
R65 CHIP RES. 1/10W J 150 Ω or RRXAJR5Z0151
RES CHIP 1608 1/10W J 150 Ω RRXA151YF002
R66 CHIP RES. 1/10W J 150 Ω or RRXAJR5Z0151
RES CHIP 1608 1/10W J 150 Ω RRXA151YF002
MISCELLANEOUS
CLN53 WIRE ASSEMBLY 5PIN 5PIN 230MM AWG26 WX1L4620-002
JS52 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
RCV51 REMOCON RECEIVE UNIT PIC-37042SR or USESJRSKK034
REMOCON RESEVER MIM-0BM8DKL-C USESJRSUNT07
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
1ESA13345
CAPACITORS
C301 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C302 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C303 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C321 CAP CHIP 5pF 3KV C XC CA3F5R05M016
C322 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C323 CAP CHIP 5pF 3KV C XC CA3F5R05M016
C325 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C326 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C327 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C328 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C329 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C330 CAP METALIZED FILM 0.068µF/250V/J or CT2E683MS041
CAP METALIZED FILM 0.068/250VDC/J/MPEF CT2E683DT051
C331 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C332 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C341 CAP CHIP 5pF 3KV C XC CA3F5R05M016
C342 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C343 CAP CHIP 5pF 3KV C XC CA3F5R05M016
C345 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C346 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C347 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C348 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C349 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C350 CAP METALIZED FILM 0.068µF/250V/J or CT2E683MS041
CAP METALIZED FILM 0.068/250VDC/J/MPEF CT2E683DT051
C351 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C361 CAP CHIP 5pF 3KV C XC CA3F5R05M016
C362 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C363 CAP CHIP 5pF 3KV C XC CA3F5R05M016
C365 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C366 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C367 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C368 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C369 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C370 CAP METALIZED FILM 0.068µF/250V/J or CT2E683MS041
CAP METALIZED FILM 0.068/250VDC/J/MPEF CT2E683DT051
C371 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
CONNECTORS
CN301 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
CN302 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
CN303 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
