FUNAI W4A-A4180DB - Mechanical Parts List

20070515 1-18-1 E9G00CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
W4A-A4180DB A
W4A-D4180DB B
W4D-D4180DB C
Ref. No. Mark Description Part No.
A1X FRONT ASSEMBLY E9G00ED 1VM223076
A2 TOP COVER E9G00ED 1VM223085
A3 MAIN CHASSIS E9400UD 0VM101353H
A4 REAR PANEL E9G00ED 1VM223073
A10! A RATING LABEL E9G00ED ----------
A10! B RATING LABEL E9G03ED ----------
A10! C RATING LABEL E9G04ED ----------
A14 BARCODE LABEL UNFIGURE E9704ED ----------
A14 A BARCODE LABEL E9G00ED ----------
A14 B BARCODE LABEL E9G03ED ----------
A14 C BARCODE LABEL E9G04ED ----------
A34 FOOT H5100UD 0VM406940A
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
2B1 DECK PEDESTAL E9600UD 1VM120055G
2B2 FRONT BRACKET E9400UD 0VM204534C
2B3 FRONT BRACKET R E9400UD 0VM416269A
2B4 EARTH PLATE E9H10UD 1VM425084
2B10 PCB HOLDER E9H10UD 1VM121066F
2B13 JACK BRACKET E9400UD 0VM416273
2B31 TAPE HIMELON H9206JD 0VM413956
2B32 DOUBLE SIDE TAPE HB200UD 0VM412870
2B45 DUST COVER(R4 PAL) E9GA0BD 1VM323812A
2B59 JACK EARTH PLATE E9600UD 1VM320623
2B76 RUBBER CUSHION(B) E9B00ED 1VM424744
2B77 RUBBER CUSHION(C) E9B00ED 1VM424745
2B84 FAN HOLDER E9H10UD 1VM323512
2B87 PCB WASHER E9H10UD 1VM425701
2L011 SCREW TAP TIGHT M3X5 BIND
HEAD+BLK NI
GBHC3050
2L013 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L014 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L017 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
2L021 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
2L022 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L030 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L033 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L043 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L044 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
2L045 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L052 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L061 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L062 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
2L071 SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
2L075 SCREW P-TIGHT M3X8 BIND HEAD+
BLK
GBHP3080
2L081 S-TIGHT SCREW M3X6 BIND
HEAD+BLACK
GBHS3060
2L082 S-TIGHT SCREW M3X6 BIND
HEAD+BLACK
GBHS3060
2L083 SCREW P-TIGHT M3X8 BIND HEAD+
BLK
GBHP3080
2L111 SCREW P-TIGHT 3X14 BIND HEAD + GBJP3140
FM1001 MOTOR DC FAN 2D65BK100100 MMEZR12XNR01
PACKING
S1 A GIFT BOX CARTON E9G00ED 1VM323976
S1 B GIFT BOX CARTON E9G03ED 1VM323980
S1 C GIFT BOX CARTON E9G04ED 1VM323981
S2 SIDE PAD E9700ED 1VM120081B
S3 SET BAG E7708UA 0DM400731D
S5 PAD E9GA0BD 1VM425619
S9 TOP PAD E9B00ED 1VM323207
ACCESSORIES
X1 REMOTE CONTROL UNIT NB617ED NB617ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C or XB0M571GLP01
DRY BATTERY R6UW/2S XB0M311MS001
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5700UD 0VM415576
X6 A,B WIRE ASSEMBLY SCART CABLE
CE1013020121410
WX1E8G00-111
X9 REMOCON BAG E9704ED 1VM422101
X20A! A OWNERS MANUAL(GER) E9G00ED 1VMN23719
X20A! B OWNERS MANUAL(SP) E9G03ED 1VMN23735
X20A! C OWNERS MANUAL(EN) E9G04ED 1VMN23741
X20B! A OWNERS MANUAL(ITA) E9G00ED 1VMN23720
X20B! B OWNERS MANUAL(SW) E9G03ED 1VMN23736
X20B! C OWNERS MANUAL(DE) E9G04ED 1VMN23742
X20C! A OWNERS MANUAL(GRE) E9G00ED 1VMN23721
X20C! B OWNERS MANUAL(GE) E9G03ED 1VMN23737
X20C! C OWNERS MANUAL(PL) E9G04ED 1VMN23743
X22A A QUICK GUIDE(GER) E9G00ED 1VMN23722
X22A B QUICK GUIDE(SP) E9G03ED 1VMN23738
X22A C QUICK GUIDE(EN) E9G04ED 1VMN23744
X22B A QUICK GUIDE(ITA) E9G00ED 1VMN23723
X22B B QUICK GUIDE(SW) E9G03ED 1VMN23739
X22B C QUICK GUIDE(DE) E9G04ED 1VMN23745
X22C A QUICK GUIDE(GRE) E9G00ED 1VMN23724
X22C B QUICK GUIDE(GE) E9G03ED 1VMN23740
X22C C QUICK GUIDE(PL) E9G04ED 1VMN23746
X22D B QUICK GUIDE(NO) E9G03ED 1VMN23747
X22D C QUICK GUIDE(HU) E9G04ED 1VMN23750
X22E B QUICK GUIDE(POR) E9G03ED 1VMN23748
X22E C QUICK GUIDE(SK) E9G04ED 1VMN23751
X22F B QUICK GUIDE(DA) E9G03ED 1VMN23749
X22F C QUICK GUIDE(RU) E9G04ED 1VMN23752
X22G B QUICK GUIDE(FI) E9G03ED 1VMN23757
X22G C QUICK GUIDE(AR) E9G04ED 1VMN23753
X22H C QUICK GUIDE(CS) E9G04ED 1VMN23754
X22I C QUICK GUIDE(RO) E9G04ED 1VMN23755
X22J C QUICK GUIDE(BG) E9G04ED 1VMN23756
X24 A SERVICE CENTER LIST HC2C0ED 0VMN03071D
X29 B OWNERS MANUAL CD-ROM E9G03ED 1VM323956
X29 C OWNERS MANUAL CD-ROM E9G04ED 1VM323957
X31 A,B HANDBILL E8G00ED 1VMN23494
X31 C HANDBILL E8G04ED 1VMN23558
X40 A WARRANTY CARD E9G00ED 1VMN23725
X42 A LABEL SERIAL NO. E5705JD ----------
X43 POST CARD E8G00ED 1VMN23493
Ref. No. Mark Description Part No.
