FUNAI W4A-A4180DB - Connectors List; Diodes List; ICs List; Coils List

20070515 1-19-5 E9G00EL
C1665 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1671 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1672 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1673 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
CAP ELECTROLYTIC 47µF/16V/M CA1C470ENE12
C1675 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
CAP ELECTROLYTIC 47µF/25V/M CA1E470ENE12
C1677 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1680 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1681 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1684 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1685 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1686 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1687 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1688 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1689 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1691 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1692 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C1693 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C1694 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1695 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1696 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1697 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1698 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1699 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1700 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1701 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C1702 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
CONNECTORS
CN1503 PH CONNECTOR (WHITE) TOP 2P B2B-
PH-K-S(LF)
J3PHC02JG017
CN1504 CONNECTOR FFC 34P IMSA-9615S-
34A-PP-A
JC96J34ER007
CN1505 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
CN1506 A AFV PCB ASSEMBLY E3B00ED E3B00AFV
CN1506 B,C AFV PCB ASSEMBLY E3B01BD E3B01AFV
DIODES
D301 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D502 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D503 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D509 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D510 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
Ref. No. Mark Description Part No.
SWITCHING DIODE 1N4148M NDTZ01N4148M
D511 ZENER DIODE MTZJT-777.5A or QDTA0MTZJ7R5
DIODE ZENER 7V5BSA-T26 or NDTA7R5BST26
ZENER DIODE DZ-7.5BSAT265 NDTA0DZ7R5BS
D512 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D555 LED MIE-534A2 or NPZZM1E534A2
LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D1501 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1502 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1503 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1506 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
DIODE SCHOTTKY SB140 or NDLZ00SB140S
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1507 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1508 ZENER DIODE MTZJT-774.3C or QDTC0MTZJ4R3
DIODE ZENER 4V3BSC-T26 or NDTC4R3BST26
ZENER DIODE DZ-4.3BSCT265 NDTC0DZ4R3BS
D1511 ZENER DIODE MTZJT-7710B or QDTB00MTZJ10
DIODE ZENER 10BSB-T26 or NDTB010BST26
ZENER DIODE DZ-10BSBT265 NDTB00DZ10BS
D1512 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1513 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1516 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1517 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1518 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B or QDTB00MTZJ18
DIODE ZENER 18BSB-T26 NDTB018BST26
D1519 ZENER DIODE MTZJT-7711B or QDTB00MTZJ11
DIODE ZENER 11BSB-T26 or NDTB011BST26
ZENER DIODE DZ-11BSBT265 NDTB00DZ11BS
D1521 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1523 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D1525 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1526 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1528 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1529 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
Ref. No. Mark Description Part No.
