FUNAI W4A-A4180DB - Capacitors List (Continued); Diodes List (Continued); ICs List (Continued); Coils List (Continued)

20070515 1-19-16 E9G00EL
C22 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 CE1JMASSLR22
C27 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
ICS
IC1 A IC AUDIO PROCESSOR MSP3407G-
QG-B8-V3
NSZBA0SP3004
IC1 B,C IC AUDIO PROCESSOR MSP3417G-
QG-B8-V3
NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-5FT LLARKBSTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-5FT LLARKBSTU100
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R4 CHIP RES. 1/10W J 120k Ω or RRXAJR5Z0124
RES CHIP 1608 1/10W J 120k Ω RRXA124YF002
R5 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
X1 RESONATOR XTAL 186 910A018432-
1030300
FXD186LXGE01
Ref. No. Mark Description Part No.
