WWW.FUNNMTB.COM
BLACK MAGIC PEDALS 2022.02.10 / REV. 0
INSTALLATION AND USE
BLACK MAGIC PEDALS
MAINTENANCE
Pedals should be serviced if: rotating pedal emits noise, rotation by hand feels rough, there is play in the bearings.
Bearings should be cleaned and regreased at least once every 12 months, or at least once every 6 months if riding
predominantly in wet conditions.Damaged bearings should be replaced.
Replace pedals with fractures in body.
1.
2.
3.
NEW PINS DAMAGED PINS
grip pins
You can remove the pins on the pedals to fine-tune the grip. Damaged or worn grip pins can be replaced using a
4mm socket wrench.
It is suggested to replace damaged pins when they are worn to the condition shown in the figure below. To ensure safe riding.
Socket wrench 4mm
