CROSSFIRE STEM 2022.09.01 / REV. 0
Please check the torque for all the bolts twice a year. Please also inspect the stem and handlebar for damage and visible cracks.
If any damage, please stop using the part. It should be replaced immediately. Failure to do so may result in serious injury.
Warning
6Nm
6Nm
INSTALLATION AND USE
No Gap
6Nm
CROSSFIRE STEM
6Nm
Install the handlebar and position the clamps, ensuring the “No Gap” markings on the clamps are at the top. Adjust the
handlebar to the preferred position, then tighten the top clamp bolts to 6Nm and leave no gaps on top.
4.
Tighten both lower clamp bolts to 6Nm or the recommended torque from the handlebar manufacturer.5.
Insert the steerer clamp bolts. Align the stem to the front wheel and then tighten the stem bolts to 6Nm.
Make sure the stem bolts are tightened before riding. Riding with a loose stem can result in serious accidents.
6.
