Funn MAMBA - Mamba Pedals Bearing and Axle Replacement Procedure; Step 1: Remove Side Cap; Step 2: Loosen Axle Nut

WWW.FUNNMTB.COM
TAIPAN PEDALS 2024.04.15 / REV. 0
WWW.FUNNMTB.COM
BEARING / Axle Replacement
step 1 :
step 2 :
02
MAMBA PEDALS
MAMBA PEDALS 2024.04.22 / REV. 0
Remove the side cap using a 6mm hex key.
Secure the axle with an 8mm hex key, then use an 8mm socket wrench to loosen the axle nut.
Be aware of the thread direction on each side of the pedal.
6mm hex key
8mm hex key
Spacer
Spacer
Axle nut
RIGHT
LEFT
Axle nut
