Timer Function
FAN- FAN+
MODE
HEATER SLEEP
CLOCK TIMER
LOCK LIGHT
0 0
C / F
Timer ON
When the air conditioner is switched off,
press the TIMER button to turn on the air
conditioner automatically at the set time.
1
Press the button to set the hour
and press the
button to set the
minute.
2
Set the air conditioner operating
mode, temperature, fan speed etc.
The air conditioner will be turned on
automatically at the set time.
NOTE: If the TIMER button is pressed
again, the timer on setting will be
canceled.
Timer OFF
When the air conditioner is running, press
the TIMER button to turn off the air
conditioner automatically at the set time.
1
Set the switch off time by pressing
the
button to set the hour and
press the
to set the minute.
Install/Replace the Remote Control
Batteries
1. Remove the battery compartment cover.
2. Install two AAA batteries (supplied). Ensure batteries are
inserted with the proper polarity.
3. Close with the battery compartment cover.
Description of the wall control unit
No Function
①
Infrared remote control receiver
②
Press the ON/OFF button to turn on the air conditioner.
③
Press the MODE button to select cooling or heating mode.
④
Press the FAN button to select fan speed.
⑤
Press the UP or DOWN button to select the desired
temperature.
1
2
3
4
5
Technical data
296
30
398
86
86
14
734
Refrigerant type/quantity R410A / 500g
Cooling capacity(W) 2637
Heating capacity(W) 3223
Input power - Cooling mode (Watt) 925
Input current - Cooling Mode (Amps) 4.2
Input power - Heating mode (Watt) 1250
Input current - Heating Mode (Amps) 5.3
Additional heating element(Watt) 500
Input supply voltage 220-240 V(AC)/ 50 Hz
Protection class IP X5
Maximum outlet airflow(max)(m³/h) 350
Maximum coach size (with insulated walls)(m) 30
Weight(kg) 27.8
E.E.R. / C.O.P 2.5 / 2.6
Fan 3 speed levels
Operating temperature From -7℃ to +43℃
English
Rev: 12-21-23
- 5 -
