15
Installation
6. Insert the right camera into the traffic
light base and secure with the two flat
self-tapping screws provided. (Fig. 25 and
Fig. 26)
Fig. 25
Fig. 26
7. Replace the lens cover over the traffic
light base and press until a “click” is
heard. The camera is now fully installed
onto the vehicle. (Fig. 27 and Fig. 28)
Fig. 27
Fig. 28
8. Repeat steps 1 to 7 to install the other
camera.
Front and Rear Camera Installation
(if purchased)
A traffic light must be installed together
with the camera. For best performance, we
recommend a Furrion traffic light.
1. Select a suitable position on front or back
of the vehicle wall that you would like to
install the camera.
2. Remove the lens cover by scratching the
slot on the side of the traffic light.
(Fig. 29)
Fig. 29
To Next Page
