27
Specifications
Specifications
SUPPLY VOLTAGE DC8 to 30V
WIRELESS FREQUENCY 2.4 GHz
WIRELESS RANGE 150m (open area)
TRANSMITTING SPEED 6 Mbps (single)
RECEIVING SENSITIVITY -88 +/-3dBm
DECOMPRESSION FORM H.264
DELAYING TIME <250ms
CAMERA
IMAGE DISTANCE Rear: <5m / Side: <12m
CMOS SIZE ⁄”
OPTICAL LENS
Rear: F2.0
Side: F2.5
IR CUT FILTER 850nm automatic
VIEW ANGLE Rear: 120˚ / Side: 65˚
CURRENT (IR ON) <500mA@12V
CURRENT (IR OFF) <350mA@12V
CAMERA PIXEL 720x480
DISPLAY
LCD POWER OFF <30mA@12V
LCD BACKLIGHT ON <500mA@12V
LCD BACKLIGHT OFF <300mA@12V
LCD SIZE 7” / 5”
LCD RESOLUTION AT 1VIEW 720 x 480
LCD BRIGHTNESS 180cd/m
2
(7” monitor); 300cd/m
2
(5” monitor)
LCD CONTRAST 800:1
(7” monitor); 350:1 (5” monitor)
LCD VIEWING ANGLE L/R80,U60,D70 (7” monitor); L/R65,U50,D60 (5” monitor)
LCD ASPECT RATIO 16:9
