Product Overview
Note: Product specifications are subject to change without prior notice.
Vision S Family Monitor Specification
4.3" Monitor 5" Monitor 7" Monitor
Operating Voltage
8 – 30Vdc
Wireless Frequency
2.4G
Rx Sensitivity
-88dBm+/-3dBm
Aspect Radio
16:9
Resolution
480x272 800x480 800x480
Max View on Screen
1 4 4
View Angle
L/R65,U50,D60 L/R80,U60,D70
Brightness
Min. 200cd/m² Min. 300cd/m² Min. 180cd/m²
Contract
350:1 600:1 800:1
Power Consumption
(@12V)
<500mA @12V (Backlight ON)
<300mA @12V (Backlight OFF)
<30mA @ 12V (Display OFF)
Operating
Temperature
-20°C to +60°C
