Product Overview
Vision S Family Camera Specification
Model
L/R Side Camera Rear Camera Doorway Camera
Operating Voltage
8 – 30Vdc
Wireless Frequency
2.4G
Wireless Range
>150m (open area)
Delay Time
<250ms
Tx Power
18dBm+/-1.5dBm
Transmitting Speed
6Mbps (Single)
Decompression Form
H.264
Camera Pixel
720x480
CMOS Size
1/3”
IR Cut Filter
850nm automatic
Optical Lens
F2.5 F2.0
View Angle
65° 120°
Image Distance
<12m <5m
Power Consumption
(@12V)
<350mA (IR OFF)
<500mA (IR ON)
Operating Temperature
-20°C to +60°C
Motion Detection
Algorithm
By video camera software
Vision S Family Camera Bracket Specification
LED Marker Marker Light Bracket
Sharkfin
Bracket
Number of
Poles
4 3 2
Wiring Color
Red — Voltage in
Black — GND
Yellow — Turn signal trigger
(left/right)
Brown — Marker Light
Voltage in
Red — Voltage in
Black — GND
Brown — Marker Light
Voltage in
Red — Voltage in
Black — GND
Installation
Position
RED for Rear
Amber for Side (Left/ Right)
RED for Rear
Amber for Side (Left/
Right)
Doorway, Rear
