Chapter 4. Maintenance
15
This unit is designed for board level maintenance, not component replacement.
4.1 Maintenace Parts
Table 4-1 Maintenance Parts
Parts Type Code No. Remarks
DU Board 03P9268 008-499-680
PNL Board PNL9194 008-481-680
MD Board 03P9270 008-499-650
IF Board 03P9269 008-499-640
INT Board 03P9271 008-499-660
LCD Unit DG52Y-5MC 000-142-310
MIC S-RX50/RU-9458 000-142-269
Magnetron E3588 000-142-270
Antenna Motor RM-9455 000-142-252
Fuse FGBO-A, 5A, 125 V 000-549-064
Program ROM PROM0359158101 008-499-730 U115, DU Board
Radome cover RSB-0060 008-440-720
Radome packing 03-118-3203 100-185-430
