1. INITIAL SETTING AND ADJUSTMENT
1-10
1.2.5 [Application] window
1. Access the [Common Installation Setting] menu and click [Basic Setting] on the
tab bar.
2. Click [Application] on the menu bar.
3. Select the primary display mode from the [Primary] pull-down list. The primary dis-
play mode is displayed when you start the ECDIS. Also, the working indicator at
the upper right changes according to the setting, and the spinner can be clicked
to return the primary display mode.
Note: [AMS] is not available for this system.
4. Click [Save] on the info bar. Several confirmation messages appear. Click [OK] to
reboot the system. To discard all changes, click [Discard Changes].
1.2.6 [Ship Name] window
1. Access the [Common Installation Setting] menu and click [Basic Setting] on the
tab bar.
2. Click [Ship Name] on the menu bar.
3. Enter your ship information. The data entered here is included in any printing.
[Ship Name]: Own ship’s name.
[Call Sign]: Own ship’s call sign
[IMO No.]: Own ship’s IMO no.
[MMSI]: Own ship’s ID
Note: Chart radar can display own ship’s data input from AIS, on the [Own Ship]
page in the [Nav Status] menu. The data entered here is not reflected to the AIS
data.
4. Click [Save] on the info bar. Several confirmation mes-sages appear. Click [OK]
to reboot the system. To discard all changes, click [Discard Changes].
: No setting
: [ECDIS] is selected.
: [RADAR] is selected.
䠖
[Conning] is selected.
To Next Page
