How to fix Furuno Marine Radar showing only two PI lines?
If your Furuno Marine Radar is only showing two PI lines when six are desired, it is likely due to an incorrect setting of the PI line interval or an inappropriate setting for the number of PI lines to display. Adjust the PI line interval. Also, check the menu setting for the number of PI lines.
Why Furuno FAR-1513 Marine Radar cannot turn on?
If your Furuno Marine Radar cannot be turned on, the cause may be a blown fuse, incorrect mains voltage/polarity, or a faulty power supply board. To resolve this, replace the blown fuse, correct the wiring and input voltage, or replace the power supply board.
What to do if Furuno FAR-1513 picture not updated?
If the picture on your Furuno Marine Radar is not updating or is frozen, this is likely due to a video freeze. Turn the power off and on again to restore normal operation.
Why Furuno FAR-1513 shows marks and noise but no echo?
If you see marks, indications, and noise but no echo on your Furuno Marine Radar, the Tx high voltage protection circuit may have been activated. Reset the power to restore normal operation.
How to fix Furuno FAR-1513 Marine Radar when range changed but picture not changing?
If the range is changed on the Furuno Marine Radar but the picture is not changing, it could be due to a defective range key, a faulty SPU board, or a video freeze-up. Try adjusting the range with the control unit or the [RANGE] box several times; if that doesn't work, the keypad may need replacement. If still not working, replace the SPU board. Alternatively, try turning the radar off and on.
Why Furuno FAR-1513 interference rejector is inoperative?
If the interference rejector on your Furuno Marine Radar is inoperative and the interference rejection level is not displayed, the issue is likely with the SPU board. Replace the SPU board.
How to fix Furuno Marine Radar target not tracked correctly?
If a target is not being tracked correctly on your Furuno Marine Radar, it may be due to poor definition of targets in sea clutter. Adjust A/C SEA and A/C RAIN.
Why cannot operate Furuno FAR-1513 Marine Radar from on-screen boxes?
If you cannot operate the radar from the on-screen boxes on your Furuno Marine Radar, the issue is likely with the SPU board. Replace the SPU board.
Why Furuno FAR-1513 shows marks but no noise when GAIN adjusted?
If, with the GAIN adjusted and A/C SEA set to minimum, marks and indications appear on your Furuno Marine Radar but there is no noise or echo, it could be due to the IF amplifier, the signal cable between the antenna and processor unit, or the video amplifier board. Replace the IF amplifier. Check the continuity and isolation of the coaxial cable (disconnect the plug and lugs at both ends before checking with an ohmmeter). Check the video coax line for a secure connection; if the connection is good, replace the SPU board.
Why Furuno Marine Radar picture is not updated with each sweep?
If the picture on your Furuno Marine Radar is not updating with each sweep, it could be due to slots in the rotating disc in the antenna unit or the motor brushes. Remove any foreign material (carbon, grease, etc.) from the slots. If the motor brushes are shorter than 6 - 7 mm, replace them.
General| Antenna Type | Open Array |
|---|---|
| Rotation Speed | 24 RPM |
| Frequency | 9.4 GHz (X-band) |
| Range | 48 NM |
| Display Size | 15 inches |
| Antenna Length | 1.2 m |
| Beamwidth | 1.2° |
Provides general guidelines for using the manual and the equipment safely, covering grammar and user responsibilities.
Details the functions and operation of the control unit RC-028, including keys, touchpad, and navigation tools.
Provides step-by-step instructions for powering the radar system on and off, including warm-up procedures.
Identifies and explains various boxes and indicators displayed on the radar screen for operational information.
Details how to access and navigate the radar's main menu, layer menus, and operate menu items.
Describes methods for inputting own ship's speed, including automatic (log/GPS) and manual options.
Provides procedures for starting and stopping radar transmission, including quick start and screen freeze recovery.
Details methods for reducing sea clutter using A/C SEA control, both automatically and manually.
Explains how to reduce rain clutter using AUTO RAIN and A/C RAIN controls for clearer radar pictures.
Describes the ACE function for automatic reduction of sea and rain clutter, including its activation and adjustment.
Explains the target alarm function for alerting navigators to targets entering specific areas with audiovisual alerts.
Details how to use Parallel Index lines for maintaining constant distance from coastlines or other ships while navigating.
Describes methods for measuring target range using fixed range rings, cursor, or Variable Range Markers (VRM).
Explains how to use Electronic Bearing Lines (EBLs) to take bearings of targets and measure range.
Explains how to display target trails as synthetic afterglows for tracking target movements, including relative or true motion.
Describes the target analyzer function for identifying dangerous targets, useful in heavy rain/snow or surface reflection areas.
Details the available radar presentation modes such as HEAD UP, COURSE UP, NORTH UP, and True Motion.
Describes how to select the radar's range scale, range ring interval, and pulselength.
Explains how to measure range and bearing between two targets using EBL and VRM functions.
Provides instructions on using marks to indicate points of interest on the radar display, including selecting mark types and colors.
Describes the performance monitor function which provides visual indication of radar transmitter power and receiver sensitivity.
Explains how to interpret alert messages displayed in the ALERT box, including alert icons, status indications, and priority levels.
Explains the minimum and maximum ranges of the radar, factors affecting them, and relevant IMO requirements.
Details the key factors affecting radar resolution: bearing resolution and range resolution.
Describes types of false echoes like multiple echoes, sidelobe echoes, and virtual images, and how to mitigate them.
Explains the operation of the SART and how to display SART marks on the radar display for detection.
Provides essential precautions and warnings for safe and effective use of the Target Tracking system.
Details the primary controls used for target tracking mode on the control unit, including TGT ACQ and TGT CANCEL keys.
Explains the different modes for target tracking (MANUAL, AUTO) and how to select them.
Provides methods for acquiring and tracking targets manually and automatically using the radar system.
Describes how to input own ship's speed data, including echo-referenced speed input.
Explains the collision alarm function, including CPA and TCPA settings for threat detection.
Explains the AIS collision alarm function, detailing CPA and TCPA settings for detecting dangerous AIS targets.
