How to fix Furuno Marine Radar showing only two PI lines?
If your Furuno Marine Radar is only showing two PI lines when six are desired, it is likely due to an incorrect setting of the PI line interval or an inappropriate setting for the number of PI lines to display. Adjust the PI line interval. Also, check the menu setting for the number of PI lines.
Why Furuno FAR-1518-BB Marine Radar cannot turn on?
If your Furuno Marine Radar cannot be turned on, the cause may be a blown fuse, incorrect mains voltage/polarity, or a faulty power supply board. To resolve this, replace the blown fuse, correct the wiring and input voltage, or replace the power supply board.
What to do if Furuno FAR-1518-BB picture not updated?
If the picture on your Furuno Marine Radar is not updating or is frozen, this is likely due to a video freeze. Turn the power off and on again to restore normal operation.
Why Furuno FAR-1518-BB shows marks and noise but no echo?
If you see marks, indications, and noise but no echo on your Furuno Marine Radar, the Tx high voltage protection circuit may have been activated. Reset the power to restore normal operation.
How to fix Furuno FAR-1518-BB when range changed but picture not changing?
If the range is changed on the Furuno Marine Radar but the picture is not changing, it could be due to a defective range key, a faulty SPU board, or a video freeze-up. Try adjusting the range with the control unit or the [RANGE] box several times; if that doesn't work, the keypad may need replacement. If still not working, replace the SPU board. Alternatively, try turning the radar off and on.
Why Furuno FAR-1518-BB interference rejector is inoperative?
If the interference rejector on your Furuno Marine Radar is inoperative and the interference rejection level is not displayed, the issue is likely with the SPU board. Replace the SPU board.
How to fix Furuno Marine Radar target not tracked correctly?
If a target is not being tracked correctly on your Furuno Marine Radar, it may be due to poor definition of targets in sea clutter. Adjust A/C SEA and A/C RAIN.
Why cannot operate Furuno FAR-1518-BB from on-screen boxes?
If you cannot operate the radar from the on-screen boxes on your Furuno Marine Radar, the issue is likely with the SPU board. Replace the SPU board.
Why Furuno FAR-1518-BB shows marks but no noise when GAIN adjusted?
If, with the GAIN adjusted and A/C SEA set to minimum, marks and indications appear on your Furuno Marine Radar but there is no noise or echo, it could be due to the IF amplifier, the signal cable between the antenna and processor unit, or the video amplifier board. Replace the IF amplifier. Check the continuity and isolation of the coaxial cable (disconnect the plug and lugs at both ends before checking with an ohmmeter). Check the video coax line for a secure connection; if the connection is good, replace the SPU board.
Why Furuno FAR-1518-BB picture is not updated with each sweep?
If the picture on your Furuno Marine Radar is not updating with each sweep, it could be due to slots in the rotating disc in the antenna unit or the motor brushes. Remove any foreign material (carbon, grease, etc.) from the slots. If the motor brushes are shorter than 6 - 7 mm, replace them.
Overview of the control unit (RCU-028) and trackball unit (RCU-030) functions.
Step-by-step guide for powering the radar system on and off.
Instructions for adjusting screen brilliance using control unit or on-screen menus.
Details on various indications shown on the radar display screen.
Explains how to access and navigate through the radar's main and sub-menus.
Instructions for setting own ship's speed, including automatic and manual input.
Procedure for selecting the data source for own ship's position.
Steps for starting and stopping radar transmission and antenna rotation.
Instructions for tuning the radar receiver, including automatic and manual methods.
Methods for reducing sea clutter using A/C SEA controls.
Techniques for reducing rain clutter using AUTO RAIN and A/C RAIN controls.
Details on the ACE function for automatic detection and reduction of clutter.
Guidance on assigning optimum radar settings for specific navigation situations.
Overview and description of available radar presentation modes.
Steps for changing the radar's range scale for optimal target viewing.
Methods for measuring target range using fixed rings, cursor, or VRM.
Instructions for measuring target bearing using EBLs and cursor.
Using offset EBL for assessing collision risk and measuring range/bearing.
Procedure for measuring range and bearing between two selected targets.
Guide on using marks to identify points of interest or targets on the radar.
Explanation of alert messages, icons, and their meanings.
Information on Search and Rescue Transponders and their detection.
Important considerations and warnings before using target tracking functions.
Overview of the control unit keys used for target tracking.
Procedures for acquiring and tracking radar targets manually or automatically.
Steps for canceling target tracking for individual or all tracked targets.
Information on setting up CPA/TCPA alarms for collision avoidance.
Details on criteria used for selecting and tracking targets.
Discussion of factors that can affect the performance of TT functions.
Overview of controls and functions related to AIS operation.
Procedures for activating AIS targets for display and tracking.
Setup for AIS collision alarms based on CPA and TCPA.
Instructions for showing/hiding radar maps and available map marks.
Overview of the control unit (RCU-028) and trackball unit (RCU-030) functions.
Step-by-step guide for powering the radar system on and off.
Instructions for adjusting screen brilliance using control unit or on-screen menus.
Details on various indications shown on the radar display screen.
Explains how to access and navigate through the radar's main and sub-menus.
Instructions for setting own ship's speed, including automatic and manual input.
Procedure for selecting the data source for own ship's position.
Steps for starting and stopping radar transmission and antenna rotation.
Instructions for tuning the radar receiver, including automatic and manual methods.
Methods for reducing sea clutter using A/C SEA controls.
Techniques for reducing rain clutter using AUTO RAIN and A/C RAIN controls.
Details on the ACE function for automatic detection and reduction of clutter.
Guidance on assigning optimum radar settings for specific navigation situations.
Overview and description of available radar presentation modes.
Steps for changing the radar's range scale for optimal target viewing.
Methods for measuring target range using fixed rings, cursor, or VRM.
Instructions for measuring target bearing using EBLs and cursor.
Using offset EBL for assessing collision risk and measuring range/bearing.
Procedure for measuring range and bearing between two selected targets.
Guide on using marks to identify points of interest or targets on the radar.
Explanation of alert messages, icons, and their meanings.
Information on Search and Rescue Transponders and their detection.
Important considerations and warnings before using target tracking functions.
Overview of the control unit keys used for target tracking.
Procedures for acquiring and tracking radar targets manually or automatically.
Steps for canceling target tracking for individual or all tracked targets.
Information on setting up CPA/TCPA alarms for collision avoidance.
Details on criteria used for selecting and tracking targets.
Discussion of factors that can affect the performance of TT functions.
Overview of controls and functions related to AIS operation.
Procedures for activating AIS targets for display and tracking.
Setup for AIS collision alarms based on CPA and TCPA.
Instructions for showing/hiding radar maps and available map marks.
General| Type | Marine Radar |
|---|---|
| Display Type | LCD |
| Transmitter Power | 25 kW |
| Antenna Type | Open Array |
| Frequency | 9410 MHz ± 30 MHz |
| Range | 0.125 to 96 nautical miles |
| Rotation Speed | 24 RPM |
| Antenna Length | 6 feet |
