1. OPERATIONAL OVERVIEW
1-6
1.5 Menu Operations
1.5.1 How to access the main menu
The main menu can be accessed from the control unit or from the on-screen box. The
[MAIN MENU] appears in the text area on the right side of the screen.
From the control unit
Press the MENU key on the control panel.
From the on-screen box
Select the [MENU] box, then press the left button.
1.5.2 How to operate the menus
1. Open the [MAIN MENU].
2. Rotate the ADJUST knob to select a layer one ([MAIN MENU]) menu item, then
push the ADJUST knob. The menu item currently selected is highlighted and
shown in reverse video.
3. Rotate the ADJUST knob to select the layer two menu item, then push the knob.
When required. repeat this step to access the layer three menu. In the above ex-
ample, [ACE] is selected, which opens the layer three [ACE] menu.
4. Rotate the ADJUST knob to change the selected setting, then push the knob.
5. Close the menu.
[MAIN MENU]
1 [ECHO]
2 [MARK]
3 [NAVTOOL]
4 [ALERT]
5 [TT•AIS]
6 [FILES]
7 [INFORMATION BOX]
8 [NAV LINE•WPT]
9 [INITIAL SETTING]
0 [RADAR INSTALLATION]
Echo processing functions
Mainly turns markers on/off.
Navigation tools (PI lines/EBL/VRM)
Sets target alarm functions; outputs alert signal.
Sets TT and AIS functions.
Manages stored data.
Sets data display box items.
Processes nav lines and waypoints.
Sets up the radar; changes function key settings.
Used by technicians and service personnel.
[ECHO]
1 BACK
2 2nd ECHO REJ
OFF / ON
3 TUNE INITIALIZE
4 PERFORMANCE MON
OFF / ON
5 PM ARC
2 / 3 / 5 / 6
6 SART
OFF / ON
7 ECHO AREA
CIRCLE /WIDE /
ALL / SIMPLE
8 WIPER
OFF / 1 / 2
9 [ACE]
0 [CUSTOM SELECT]
[ACE]
1 BACK
2 SIGNAL ENHANCEMENT
1 / 2 / 3
3 SUPPRESS SECTOR
START : 000
ANGLE : 000
[MAIN MENU]
1 [ECHO]
2 [MARK]
3 [NAVTOOL]
4 [ALERT]
5 [TT•AIS]
6 [FILES]
7 [INFORMATION BOX]
8 [NAV LINE•WPT]
9 [INITIAL SETTING]
0 [RADAR INSTALLATION]
Menu selection is
highlighted and in
reverse video.
Select menu items with brackets “[ ]” to
access the layer three menu items.
Layer one (MAIN MENU) Layer two Layer three
To Next Page
