1. OPERATIONAL OVERVIEW
1-72
1.50.2 Alert list
The alert list displays the names of violated alerts, including the time and date violated.
Up to 100 alerts are stored in the internal memory. Unacknowledged alarms are dis-
played first in the list (in red text), in the order in which they appear in the [ALERT] box.
Unacknowledged warnings are displayed in the list (in yellow-orange text), in the order
in which they appear in the [ALERT] box.
Cautions are displayed in the list (in yellow text), in the order in which they appear in
the [ALERT] box.
An unacknowledged alert can be acknowledged from the list by selecting it, the press-
ing the left button. To erase the data for the number selected, press the left button
again. To erase all alert indications, select [REFRESH DATA], then press and hold the
left button.
To display the alarm list, place the cursor in the [ALERT] box and press the right but-
ton.
To change pages, select Next, then press the left button.
Alert title and code
Alert description
Date and time of alert
Displayed page/Pages available
[ALERT LIST (1/2)]
1 BACK
192 NEW TARGET
TT NEW TARGET
03/APR/2015 06:45
2 190 TARGET CAPACITY
TT TARGET 95% (AUTO)
03/APR/2015 06:50
3 190 TARGET CAPACITY
AIS DISPLAY FULL
03/APR/2015 06:15
9 REFRESH DATA (L=CLEAR)
0 NEXT
Alert icons
192 NEW TARGET
TT NEW TARGET
03/APR/2015 06:45
Alerts are displayed in the same color as their
alert icon.
