1. OPERATIONAL OVERVIEW
1-11
1.10 How to Customize Operation
Several operation items can be customized to suit your needs.
1. Open the [MAIN MENU].
2. Select [INITIAL SETTING], then push the ADJUST knob.
3. Select [OPERATION], then push the ADJUST knob.
4. Referring to the table below, select the appropriate menu item to customize.
*: Non-IMO radars only, available only for [SIMPLE] display mode. See
section 1.51 for details regarding display modes.
5. Rotate the ADJUST knob to select the appropriate setting, then push the knob.
6. Close the menu.
1.11 How to Select the Interface for Heading Input
When a gyrocompass is connected, the ship’s heading appears on the right side of the
screen, in the data display area.
Heading input format can be selected as follows:
1. Place the cursor on the [HDG] box at the top-right of the screen, then press the
right button. The [HDG] context menu appears.
2. Select [HDG SOURCE], then push the ADJUST knob.
3. Select [AD-10] or [SERIAL] as appropriate, then push the ADJUST knob.
This refers to the type of connection, [AD-10] is for AD-10 format (FURUNO orig-
inal) connection, [SERIAL] is for serial connections.
4. Close the menu.
Note: The heading sensor must be able follow a minimum ROT of 20° per second.
Heading sensors with a lesser capability may degrade the performance of echo aver-
aging, trails and TT. The data refresh rate should also be as short as possible. If the
refresh rate is too long, the ability to follow courses lessens, thereby affecting the per-
formance of echo averaging, trails and TT.
Menu items Description Available settings
WHEEL DRIVE Sets the direction of the wheel drive
(scrollwheel).
[NORMAL], [RE-
VERSE]
KEY BEEP Changes the key beep volume. [OFF], [LOW], [MID],
[HIGH]
OWN SHIP VECTOR Select how the own ship vector is
displayed.
[OFF], [HDG],
[COURSE]
STERN UP RM HEAD UP RM display is reversed. [ON], [OFF]
GUIDANCE* Turns operational guidance on/off. [ON], [OFF]
SHUTTLE FERRY Sets the shuttle ferry mode to use. [OFF], [MODE1],
[MODE2]
SENSITIVITY Adjusts sensitivity for optional
mouse/trackball.
[1], [2], [3], [4], [5]
To Next Page
