Furuno FAR-1513 - APPENDIX 7 PARTS LOCATION

AP-27
APPENDIX 7 PARTS LOCATION
This section shows the location of PC boards inside the equipment which can be replaced. For
information on parts, or to replace a part, consult your local FURUNO dealer.
Processor unit RPU-024 (AC and DC type)
AC_PWR moduleAC_PWR module
AC_PWR or DC_PWR moduleAC_PWR or DC_PWR module
FRP_TB Board
03P9601
FRP_TB Board
03P9601
SPU Board
03P9547
SPU Board
03P9547
AC_FIL
module
AC_FIL
module
AC_FIL
or
DC_FIL
module
AC_FIL
or
DC_FIL
module
Remove FRP_TB Board to
show SPU Board 03P9547
DC_PWR moduleDC_PWR module
FRP_TB Board
03P9601
FRP_TB Board
03P9601
DC_FIL
module
DC_FIL
module
