1. OPERATIONAL OVERVIEW
1-15
*
1
: This menu is not available for IMO type and the setting is fixed to [TRUE].
*
2
: Has the same effect as selecting the True Motion presentation mode.
1.14.1 How to reset the user settings
1. Select the [USER SET] box, then press the right
button to display the [USER SET MENU].
2. Select [PILOT SETTING], then push the ADJUST
knob.
3. Select [YES], then push the ADJUST knob.
4. Close the menu.
Note 1: Items not shown in the above table keep their
previous settings when [PILOT SETTING] is activated.
Note 2: TT tracking is continued after [PILOT SETTING]
is activated.
Note 3: The radar map displays the same map as before [PILOT SETTING] is activat-
ed.
1.14.2 How to store/load user settings
1. Select the [USER SET] box, then press the right button to display the [USER
SET MENU].
2. Select [USER1(2) LOAD] or [USER1(2) SAVE] to recall or save user settings, re-
spectively, then push the ADJUST knob.
3. Select [YES], then push the ADJUST knob.
4. Close the menu.
When loading settings, the following points apply:
• If the newly loaded settings cannot be applied to items not listed in the table above,
then these items keep their previous settings.
• TT tracking is continued after the settings are loaded.
• The radar map displays the same map as before the settings were loaded.
Continued from previous page
Vector mode [REL] [VECTOR] box
Vector time [6 MIN]
AZ1 [OFF] [AZ1] box
AZ2 [OFF] [AZ2] box
TT acquisition mode [MAN50] [TT TARGET] [TT SELECT]
AIS display [DISP ALL] [AIS] box
Association [ON] (TT > AIS) [MAIN MENU] [TT•AIS] [ASSOCIATION]
[ASSOCIATION TGT]
Lost Target Alert [OFF] (Disabled) LOST TARGET ALERT box
CPA/
TCPA
alarm
ON/OFF [ON] [CPA LIMIT] box
CPA [2 NM]
TCPA [12 MIN]
Function Setting(s) Menu/On-screen box
[USER SET MENU]
1 PILOT SETTING
NO / YES
2 USER1 LOAD
NO / YES
3 USER1 SAVE
NO / YES
4 USER2 LOAD
NO / YES
5 USER2 SAVE
NO / YES
To Next Page
