Furuno FELCOM 12 Installation Manual

1
1. SYSTEM CONFIGURATION
Antenna Unit
IC-112
Ground wire
Ship’s mains
24 VDC
AC/DC Power
Supply Unit
PR-300
Ship’s mains
100/200 VAC
24 VDC
Communication Unit
IC-212
Terminal Unit
IB-581
Keyboard
Printer
PP-510
24 VDC
Distress Alert Unit
IC-302
Received Call Unit
IC-303
Terminal Unit
IB-581
24 VDC
24 VDC
EGC Printer
PP-505
Terminal Unit
IB-581
or IBM Compatibile
Personal Computer
External Navigation Device
I/F Box
OP16-14
: Standard Supply
: Optional Supply
*: Mandatory for EGC operation as required by IMO Res. A. 664(16).
Figure 1-1 System configuration
*
