System Configuration
JOINT BOX
RADAR SENSOR
DRS4A/DRS6A/DRS12A/DRS25A
OR
RADAR SENSOR
DRS2D/DRS4D
DISPLAY UNIT
MU-155C/170C
VIDEO IN
(CCD CAMERA)
LINE OUT
(SPKR, ETC.)
RECTIFIER
RU-1746B
12-24 VDC
MIC IN
(MICROPHONE)
DISPLAY CONTROL UNIT
DCU12
CONTROL UNIT
MCU-001
AND/OR
2
HUB
GPS NAVIGATOR
GP-320B
AIS RECEIVER,
HEADING SENSOR or
EXTERNAL BUZZER
USB DEVICE
(MOUSE, KYBD)
NMEA 2000
(SENSOR, ETC.)
POWER SUPPLY UNIT
PSU-013
1
: Standard Supply
: Optional Supply
: Local Supply
1
For 25 kW radar sensor
2
Max. two units total
PROCESSOR UNIT
MPU-001
FISH FINDER
(DFF1, ETR-6/10N, ETR-30N)
(under development)
100/110/220/230 VAC
