Furuno PG-700 - System Configuration

v
SYSTEM CONFIGURATION
The solid line below shows the basic system configuration.
SENSOR
PG-700
JUNCTION BOX
FI-5002
*: NavNet 3D, FI series instrument, etc.
**: Not necessary if FURUNO CAN bus network supplies power.
12 VDC**
FURUNO CAN bus Device*
