1818
CONTROL DESCRIPTIONS
1 POWER AND STATUS LED’S:
This displays ‘green’ if the amplifier has been correctly powered up and ‘red’ if any faults are present.
2 BASS BOOST:
Set the bass boost switch to increase the bass at 45Hz. Selectable from 0dB, 6dB and 12dB gains
3 LOW PASS:
Ensure the crossover frequency is set at 100Hz or below. This feature is designed to filter out all mid
to high frequencies that only full range speakers should produce. Note: Failure to do so could result in
speaker damage.
MONOBLOCK AMPLIFIER
EN-AM6001, EN-AM8001
7
8
9
10 11
1 2 3 4 5 6
