Installation, Operation, and Maintenance Manual # 509252 Rev R 119
Figure 48. Blower Components
Blower Cover
Ground
Connections
Capacitor Housing
J11
Ground
Screw
Blower Wheel
Motor (B10)
F3e0017
Ground
Strap
