Installation, Operation, and Maintenance Manual # 509252 Rev R 123
Irradiators
Irradiators
Table 26 lists the various Fusion UV Systems Irradiator models and cooling method.
NOTE: All air flow specifications assume standard air density of 1.20 kg/m
3
(0.075 lbs/ft
3
). Remote blower specification must be corrected for air density
variations at customer site.
Cooling:
I300M/I310M/I310M-D/I311N/I311M-D: Requires a remote pressure blower.
I300MB/I310MB/I310MB-D: K300M modular blower mounts on top of
the irradiator and is powered by the
P300M/P300MQ power supply.
Reflector: Polished and brightened aluminum elliptical reflector with protective
aluminum oxide coating. Focus is 53.3 mm (2.1 inches) below
irradiator base rails.
The standard reflector has R500 coating. Optional reflectors have
R350 or Dichroic (cold) coatings.
Interlocks: Photoresistor assembly
Air pressure switch
Weight: 12.0 kg (26.5 lbs) with modular blower.
7.3 kg (16.0 lbs) without modular blower
Table 26. Irradiator Models and Details
System Power Supply Irradiator Designation Cooling Method
F300S/
F300SQ
P300M/P300MQ/
P300MT
I300M/I310M/I310M-D/
I311M/I311M-D
Remote cooling (Note 1) 2.8 m
3
/min
(100 cfm) at 695 Pa (2.8 H
2
O) inlet
pressure
I300MB/I310MB K300M Modular Blower
Table 27. Power Inputs from P300M/P300MQ/P300MT
Magnetron Power: 695 mA+45mA @ 3900 VDC
Filament Voltage:
STANDBY
115 VAC
100% Power 85 VAC
Blower Voltage 2.0 A @ 200-240 VAC
