Installation, Operation, and Maintenance Manual # 509252 Rev R 121
Appendix A. Specifications
This appendix outlines the various characteristics of major components of F300S and
F300SQ systems.
System
Power Supply
The following table provides the F300S and F300SQ system power supply
specifications.
Table 24. System Operating Requirements
Ambient Operating Temperature 0-45°C
Relative Humidity 30-95%
Table 25. F300S and F300SQ System Power Supply Specifications
Mechanical PM300M/P300MQ P300MT
Length 584 mm (23”) 400 mm (15.75”)
Height 213 mm (8.4”) 179.5mm (7.07”)
Width 353 mm (13.9”) 353 mm (13.9”)
Weight 30.9 kg (68 lbs.)
Weight w/QRO 40.3 kg (88.6 lbs.)
Stacking 3 units maximum
Finish Stone gray textured polyurethane enamel
Utilities
1 Phase 50/60Hz
Power 200/208/240 VAC +10%
Control Power +12VDC, +5VDC
supplied by transformer
and rectifiers on the
PWB
