Replacement Parts
142 F300S/F300SQ Ultraviolet Lamp System
I300M/I310M Irradiator Parts List
Table 33 lists the various replacement parts available for Fusion UV Systems I300M
and I310M Irradiators.
Kit, RF detector RF-1 079961 1
Kit, retrofit, relay coil resistor assemblies — 528641 1
Tool, contact removal — 043041 1
Table 33. I300M/I310M Irradiator Parts List
Description
Reference
Designator
Part Number
Bulb, UV, (standard) BF9H2 — 558432
Bulb, UV, (optional) BF9D — 558434
Bulb, UV, (optional) BF9V — 558437
Bulb kit, 6” BF9H2 (1 bulb) — 558442
Bulb kit, 6” BF9D (1 bulb) — 558444
Bulb kit, 6” BF9V (1 bulb) — 558447
Bulb kit, 6” BF9H2 (2 bulbs) — 570202
Bulb kit, 6” BF9D (2 bulbs) — 570204
Bulb kit, 6” BF9H2 (3 bulbs) — 570212
Bulb kit, 6” BF9D (3 bulbs) — 570214
End reflector, R500 (1 pc.) — 029831
End reflector, R350 (1 pc.) — 079246
Harness, for I30xM and I31xM-D series Irradiators (J10) — 090426
Harness, for I31xM series Irradiators (J10) — 090423
Hex nut, plastic, HV connector J10 — 254101
Kit, magnetron, for all I3xxM series Irradiators — 078612
Table 32. Accessory Parts List (continued)
Description Ref P/N
Quantity
F300S/F300SQ
Modular
Blower
Remote
Cooling
