Fusion MS-AM504 - Specifications

Specifications
Signal to Noise >95dB
Separation >60dB
Input Sensitivity 300mV - 8V
LP Variable Crossover 40Hz - 160Hz @ 18dB/octave
HP Variable Crossover 40Hz - 600Hz @ 18dB/octave
Variable Bass Boost 0 - + 18dB @ 45Hz
Variable Subsonic Filter 20Hz - 55Hz @ 18dB/octave
Input Impedance 20kΩ
Damping factor >200
T.H.D 0.05%
Fuse Ratings 2 x 25A
Dimensions(mm) 229 (W) x 366(L) x 53(H)
12.6 Volt power output specification
50 Watts RMS x 4 @ 4Ω 1% THD+N
75 Watts RMS x 4 @ 2Ω 1% THD+N
150 Watts RMS x 2 @ 4Ω Bridged 1% THD+N
14.4 Volt power output specification
65 Watts RMS x 4 @ 4Ω 1% THD+N
100 Watts RMS x 4 @ 2Ω 1% THD+N
200 Watts RMS x 2 @ 4Ω Bridged 1% THD+N
