Page #5 background imageLoading...
Page #5 background image
For additional information, go to
www.fusionentertainment.com and contact Tech Support.
Specifications
General
Weight 556 g (19.6 oz.)
Water resistance IEC 60529 IPX5
Operating temperature range From 0 to 50°C (from 32 to 122°F)
Storage temperature range From -20 to 70°C (from -4 to 158°F)
Input voltage From 10.8 to 16 Vdc
Fuse 15 A
Current (max.) 15 A
Current (muted) Less than 350 mA
Current (standby) Less than 5 mA
Compass-safe distance 15 cm (5.9 in.)
On-board, Class AB Amplifier
Output music power per
channel
45 W max. x 4 channels at 4 Ohms
per channel
Total output music power 180 W max.
Tuner Europe and
Australasia
USA Japan
FM radio
frequency range
From 87.5 to
108 MHz
From 87.5 to
107.9 MHz
From 76 to
95 MHz
FM frequency
step
50 kHz 200 kHz 50 kHz
AM radio
frequency range
From 522 to
1620 kHz
From 530 to
1710 kHz
From 522 to
1620 kHz
AM frequency
step
9 kHz 10 kHz 9 kHz
Stereo Dimension Drawings
Front Dimensions
À
160 mm (6.3 in.)
Á
71.5 mm (2.8 in.)
Side Dimensions
À
32 mm (1.25 in.)
Á
52 mm (2 in.)
Â
50 mm (2 in.)
Top Dimensions
À
130 mm (5.1 in.)
Á
32 mm (1.25 in.)
Â
20 mm (0.8 in.)
Appendix 3
