FUTABA 4VF-FM - Page 12

1010
1010
10
BEFORE USE
RECEIVER
R127DF
Battery connector
Antenna
R115F (not for USA)
FP-R115F
1
2
3
4
5
SERVO
<ACCESSORIES>
The following items are supplies with
the set:
-Spare servo horn: Use to match the
application.
-Servo mounting parts: Rubber bush-
ing, grommet, wood screw
Crystal
The crystal is replaced from the back of
the receiver.
7
6
5
4
3
2
1
B
Dual Conversion
FP-R127DF
FM
7CHANNEL
RECIVER
Antenna
Crystal
The crystal is replaced from the side of
the receiver.
Output / battery connector
"1": Aileron servo (CH1)
"2": Elevator servo (CH2)
"3": Throttle servo (CH3)
"4": Rudder servo (CH4)
"5": (Not used) (CH5)
"6": (Not used) (CH6)
"7": (Not used) (CH7)
"8": (Not used) (CH8)
"B": Battery connector
D
UAL
ONVERSION
C
FP-R148DF
FM
8 CHANNEL
MICRO
RECEIVER
1
2
3
4
5
6
7
8/B
R148DF
Antenna
Mounting flange
Servo horn
To receiver
S3003
S3101
