39
DATA SETTING
Gyro Gain Adjustment
Initial value: 100%
Performs gyro sensitivity adjustment. Two-point gain adjustment is
possible. The setting range is 0 to 100%. When "A: or "N" is
displayed in accordance with operation mode setting, the GY501
operates in the AVC mode and Normal mode, respectively. The gain
display indicates the actual gain, and changes with transmitter
remote gain adjustment.
Gyro Reverse
Initial value: NOR
Sets the direction of operation of the gyro.
Displays the receiver power supply voltage.When the voltage drops
to 3.8V, "LOW BAT" is displayed. In the AVCS mode, "A" is
displayed. When the rudder neutral full reset operation was per-
formed, the "****" mark, which indicates execution, is displayed. In
the AVCS mode, when there is a difference between the transmitter
rudder neutral position and the GY501 neutral data, the " " mark is
displayed.
