DATA SETTING
Gain Tracking
Initial value: +0%
Adjusts left and right tail stopping. It is used at 0% as standard, but
use this adjustment when pirouette stopping cannot be adjusted using
the CDI parameter. For example, when pirouette stopping resembles
hunting, or right turn pirouette stopping drifts, shift Trk in the +
direction. In the reverse case, shift Trk in the - direction.
If Trk is large, a left and right pirouette speed difference will be
produced. Therefore, adjust gain tracking with the smallest possible
value. The setting range is -20% to +20%.
Servo Frame Rate
Initial value: NOR
Sets the servo output frame rate. The transmitter frame rate (Nor) or
1/2 the transmitter frame rate (High) can be set. Normally, use at
"Nor".
