FUTABA T26SZ - Page 103

103
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
ŷƈƏƈƐƈƗƕƜŃŝŃŪųŶŃžŶƓƈƈƇƀ
Displaying data from the speed
The speed screen displays and sets the speed data from an
SBS-01/02G (GPS sensor) sold separately.
The speed of the aircraft during flight can be displayed.
After flight, the maximum speed during flight can be
viewed. Because this speed is based on position data from
a GPS satellite, the ground speed is displayed instead of
air speed. Consequently, with a head wind, the displayed
speed decreases and with a tail wind, the displayed speed
increases.
*AGPSsensormustbeinstalledintheaircraft.
ŤƏƄƕƐŃƖƈƗƗƌƑƊŃƚƋƈƑŃƖƓƈƈƇŃƌƑƆƕƈƄƖƈƖŃ
1. Tap Alarm and choose from Buzzer, Voice, and
Inhibit.
2. Choose "Inhibit" for Vibrator if not using the vibrator
alarm. If using vibrator, choose one of the three
types.
3. Tap Limit [xxx km/h].
4. Adjust the rate using the
"▼▼""▼""▲""▲▲"
buttons.
 ,QLWLDOYDOXHŃNPKŅNPK
 $GMXVWPHQWUDQJHNPKaNPK
Ń/LPLW
≧
Ņ/LPLW
*When the screen is tapped for one second, the rate is reset
to the initial value.
5. To terminate the input and return to the original
state, push the EXIT button.
*Speed alarm precaution
Since the GPS speed sensor displays the ground speed, it
cannot be used as a stall alarm. For example, an aircraft that
stalls at 50km/h will stall if the tailwind is 5km/h or greater
even through 55km/h is displayed by ground speed. In
DGGLWLRQZLWKDQDLUFUDIWWKDWZLOOGLVLQWHJUDWHLQPLGÀLJKWDW
400km/h at an over-speed alarm, when the headwind reaches
30km/h the airplane will disintegrate in midair due to over
speeding even at a ground speed of 370km/h.
Setsthespeedon
whichthealarm
operates.
●
Tap the [GPS] button in the Telemetry screen to call the
setup screen shown below.
Max.andmin.values
sincethepowerwas
turnedONwilldisplay.
Speed
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
*The GPS sensor is necessary, and is sold separately. Mount and
connect the sensor in accordance with the sensor instruction
manual.
↑Anupwardarrow
indicatesthealarmwill
soundwhenthespeed
reachesaboveyourset
value.
↓Adownwardarrow
indicatesthealarmwill
soundwhenthespeed
reachesbelowyourset
value.
ReferenceandDistancemodeworkinconjunctionwithDistance
discussedontheprevioustwopages.
●
