FUTABA T26SZ - Page 138

138
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
$,/
$,/
AIL3
(ChipAileron)
AIL4
(ChipAileron)
AIL1
(MainAileron)
AIL2
(MainAileron)
FLP3
(BrakeFlap)
FLP4
(BrakeFlap)
ŤŬů ڀŃťƕƄƎƈŃƳƄƓ
[Corresponding model type]: Airplane/
JOLGHUÁDSVRUPRUH
This mix operates the brake flaps (FLP3/4)
in the aileron mode. When the aileron stick
is manipulated, the aileron and brake flaps
perform the aileron operation simultaneously
and the operation characteristic of the roll axis is
improved.
ŏ7KHDLOHURQOHIWDQGULJKWPL[LQJUDWHVFDQEH
DGMXVWHGIRUHDFKÁDSVHUYR
ŏ$PL[LQJFXUYHFDQEHVHW
ŏ0L[LQJGXULQJÁLJKWFDQEHWXUQHG212))E\
setting a switch. (Always ON at [--] setting)
ŏ/LQNLQJFDQEHVHW/LQNWKLVPL[WRRWKHUPL[HV
ٴ ŶƈƗƗƌƑƊŃƐƈƗƋƒƇ
●
Tap the INH item.
(ON is displayed.)
●
When setting a switch, tap to the [--] item of the
switch and tap the screen to call the selection
screen, and then select the switch and set its ON
direction. (Always ON at "--" setting)
(For a description of the switch selection method,
see the at the back of this manual.)
●
7DSWKHOHIWRUULJKWEXWWRQRIHDFKÁDSVHUYR
Adjust the mixing rate.
*When the mixing direction is reversed by the linkage,
adjustments can be made by reversing the mixing rate
polarity (+ or -).
●
A mixing curve can be set.
(For a description of the curve setting method, see
the description at the back of this manual.)
●
To set linking, tap the Link item.
Set it to ON and tap the screen.
●
Select [AIL
→
Brake flap] at the model menu
and call the setup screen shown below.
Adjustmentofeach
flapservo
Currentlyselectedconditionname
● Mixingcurvesetting
(Foradescriptionofthe
settingmethod,seethe
descriptionatthebackof
thismanual.)
Left/rightoverall
adjustmentatRateA
andRateB
Activatethefunctionby
tappingthe[INH].
Conditiongroup/single
modeselection(Gr./Sngl)
TheON/OFFswitchof
mixingischosen.
Tosetlinking,taptothe
[OFF]item
●
Return to Model menu
