154
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
([DPSOH6HWWLQJWKUHHD[LVXVLQJD*<$DQG*<$
ŏ:LQJW\SH$LOHURQVHUYRVPRXQWHGIXVHODJHVHOHFWHG
ŏ6HW
5CH → Gyro
(GYA451AIL),
7CH → Gyro2
(GYA451ELE),
8CH → Gyro3
(GYA450RUD),
ControlandTrim → "--"
: at
the Function menu of the Linkage menu.
ŏ*\URVHWWLQJRIWKH0RGHOPHQX
*Set so that Rate 1 is turned on at the back position of switch E
and Rate 3 is turned ON at the front position. Since switch E is
turned OFF at the center, Rate 2 remains [INH].
Rudderservo
Elevatorservo
Aileronservo
S.BUS2port
S.BUSReceiver
GYA451
GYA451
GYA450
GAIN0％
AVCS
NORMAL
WhenAVCSisusedwe
recommendthatthe
sensitivityCHbesetto
the3-position.
Rate ACT Type Switch Gyro Gyro ２ Gyro ３
1 OFF/ON GY SE AVCS:60% AVCS:60% AVCS:60%
2INH
3 ON/OFF GY SE Normal:60% Normal:60% Normal:60%
