192
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
GyrosettingCGY770R
T26SZ
T26SZ
S.I/F
P.BOX
CGY770R
CGY770R
WirelessTuningsfunctionlist
-FLT.TUNE
BaseGain:Gyrobasegainsetting
CYC.Rt:Cyclicratesetting
Cnt.AuthAIL:ControlAuthorityAileron
Cnt.AuthELE:ControlAuthorityElevator
EXPO.:Exponential
FLT.Styl:Flightstyle
ELE.Comp:Elevatorprecompensation
-SWH.BASIC
SWS.Rate:Rateadjustment
PIT.Rate:Rateadjustment
SWS.Ring
-GovernorBasic
GOVGain:Governorgain
LLmt.Lrpm:LowlimitLRPM
LLmt.Hrpm:LowlimitHRPM
-FlightTuneExpert
HeadHldA:Headholdaileron
StopTuneA:Stoptuneaileron
HeadResp:HeadResponse
HeadHldE:Headholdelevator
StopTuneE:Stoptuneelevator
-RudderExpert
EXP.AVCS:RudderexponentialAVCS
EXP.NORM:RudderexponentialNORMAL
CNT.DlIn:Controldelayin
CNT.DlOut:Controldelayout
ANG:Pirouettespeed
TailResp:Tailresponse
GY.Gain:Gyrogain
F/F.RateU:Feedforwardrateupside
F/F.RateD:Feedforwardratedownside
ACC.Gain:Accelerationgain
B.Wirelesstunings:Gyrotuningscanbemadewirelessly.(Limiteditems)
Notes
:KHQXVLQJWKHZLUHOHVVWXQLQJIXQFWLRQVHW
the telemetry function to ACT.
The wireless tuning can be
FASSTest or
7)+66$,5
Donotsetduringflight.Makesettingswhen
theaircraftisonthegroundandthemotor
andenginearestopped.
A.Wiredconnection:Advancedsettings(allfunctionssameasGPB-1)
CGYConnectionCable(includedwithgyro)
Notes
,IWKH76=DQGJ\URDUHQRWFRQQHFWHGWKH
gyro setting value cannot be changed.
ŪƜƕƒŃƖƈƗƗƌƑƊ
The T26SZ has the same functions as the GPB-1.
The CGY770R can be set up from the T26SZ
screen by connecting to the T26SZ. Some functions
can be set wirelessly.
WARNING
DonotconnectthegyroandT26SZconnectioncord
totheRPMport.
*Thereisariskofbreakdownorburning.
