200
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
GyrosettingCGY770R
GyroSetDir---1
GyroSetDir---2
GyroSetDir---3
Tensplace
1
2
3
1
1
1
3
3
3
2
2
2
4
4
4
Mounting
direction
Sensor
direction
Onesplace Onesplace
GyroSetDir---4
GyroSetDir---5
GyroSetDir---6
4
5
6
1
1
1
3
3
3
2
2
4
4
4
Tensplace
Mounting
direction
Sensor
direction
Onesplace Onesplace
*Depending on the type of mounting plate,
it is also possible to mount as shown in
WKH¿JXUH
*Depending on the type of mounting plate,
it is also possible to mount as shown in
WKH¿JXUH
2
SwashBasic
SwashBasic
Thegreendisplayisthecurrentstate.
This menu is utilized to perform the basic setup of swash motion.
"
SWH. BASIC
"
screen from the
"
BASIC MENU
"
screen.
The CGY770R is compatible with the following six types swash
plate.
WARNING
Donotconnecttheservotothegyrosuntilyouselectthe
servotypeinthe"SWH.BASIC"menu.
*Iftheservotypeisincorrect,itispossibletodamagetheservosorCGY.
(1) Setup style
Setupstylecontainsaprovensetofparameterswhicharegoodfornot
only3DbutalsoF3Cflying.F3CModeandL.SCALE(Largescalemodel)
Modeareforuniqueorspecialtuningtypesonly.
*Whenthestyleischanged,settingofAIL/ELE/RUDisre-initializedand
defaultsarechanged.
L.SCALE:Initialparametermodecorrespondingtoalargemachinewitha
totallengthof2.5
mormore.
(2) Gyro Set Dir: Mounting direction
Settherollaxis,pitchaxis,yawaxisaccordingtothemountingdirection
ofCGY.WhentheLEDontheGxsidefinishesblinking,pleaseturnthe
poweroffandonagaintoconfirmthatitisworkingproperly.
Setting:1~6Initialsetting:1
WARNING
Ifyoudonotturnthepowerbackonafterchanging"GyroSetDir",thegyro
willnotoperateproperly,thereisariskofcrashing.
(3) Servo Type
Thisselectstheswashservotypes. Therearefour typesormodes oftheservo driving
frequencyselection,AN:70
Hz,DG:95 Hz,DG:140 Hz,DG285 Hz,and760 μs.AllFutaba
digitalservoscanbeoperatedwithfastestDG:285
Hzmodebutsomeofotherbrandsof
servosdonotsupportDG:285
Hzmode.Inthiscase,selecttheproperservodrivingfre-
quencyperthemanufacturerʼsspecifications.
Setting:DG:285Hz/AN:70Hz/DG:95Hz/DG:140Hz/DG:760uS/URmode
Initialsetting:DG:285
Hz
WARNING
TheservotypeparameterwithintheCGYmustmatchthetypeofservoyouare
using.IncorrectsettingmaydamagetheCGYortheservo.Incorrectsettingmayalso
resultinalossofcontrolduringflight.
