201
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
GyrosettingCGY770R
H1
SwashType
SwashBasic
SwashBasic
ELE
PIT AIL
H3-120
ELE
PIT AIL
H3-140
ELE
PIT AIL
H3-90
ELE2
ELE
PIT AIL
H4-00
ELE2
FRONT
ELE
PIT
AIL
H4-45
ELE
PIT
AIL
H-1
(4) SWASH Type: Swash change to plate type
Selecttheswashplatetype.Whenyouchangethesetting,otherdata
isinitialized.
Setting:H3-120  /  H3-140  /  H3-90  /  H4-00  /  H4-45/H1 Initialsetting:H3-120
WARNING
Alloftheswashplateparametersare resetwhentheswashplate
typeischanged.Doingsoeliminatesanypossibleerrorsormalfunc
-
tionswithinthesystem.Afterchangingtheswashplatetype,Please
proceedthroughtheentiresetupprocessonceagainbeforeattempt
-
ingtoflythemodel.
AIL------------------ Aileronservo
ELE----------------- Elevatorservo
PIT--------Collectivepitchservo
ELE2-----Secondelevatorservo
Yourtransmittershouldberesettothedefaultsettingsandtheswash
platetypeselectedwiththetransmittershouldbeset to"H-1"orsingle
servomode.AllCCPMmixingissetupandhandledintheCGY,andthe
transmitterfunctionsshouldnotbeused.Beforestartingmodelset-
up,besurethatalldualrates,pitchcurve,andendpointvaluesaresetto
100/100.
(5) Servo Dir #: Servo direction #
Usingdifferentservocombinationswillcreatetheproperswashplate
servomovementinelectronicCCPMmodels(eCCPM).IntheH3-xx
swashmode,threeoftheswashservosdirectionsarechangedbypress
-
ingtheServoDir#.Choosethecombinationnumberwhichproduces
levelswashplatetravelwithacollectivepitchinputfromthetransmit
-
ter.Thereare8combinationchoicesfortheH3-xxswashmode.OnH4-
xxswashmode,thereare16combinationchoices.Afterselectingthe
combinationnumber,aileron,elevator,pitch,and2ndelevatorservo
parametersareautomaticallyset.
Note:Occasionallytheaileronorelevatorfunctiondirectionsarereversed
eventhoughcollectivepitchdirectioniscorrect.Inthiscase,usethe"SWS.
Dirparameteronthefollowingscreen(4/7)tofixthislater.
