GyrosettingCGY770R
SwashBasic
SwashBasic
(6)AIL, ELE, PIT. Ntr:
Servo neutral adjustment
Adjusttheneutralpositionofthe swashservo(aileron,elevator,pitch,
secondelevator).Thesecondelevator(ELE2)isdisplayedonlywhenthe
swashtypeisH4-xx.
Settingranges:+240~-240Initialvalue:0
(7) SWS. Dir: Swash direction setting
Thisselectstheaileron,elevatorandcollectivepitchdirection.Reverse
thedirectionwhenthestickmovementandswashmovementareop
-
posite.Eachtimeyoupressthe+/-button,thepolarityswitches.
(8) SWS. Rate: Rate adjustment
TheSwashRatesettingsareusedtosetaknownbasecyclicthrowforthe
gyrotocalculatethecompensationsandgainscale.Thisvaluedoesnot
representthetotalcyclicthrow,butrathershowsthegyroaknownpoint
forthegyrotounderstandthehelicoptersgeometry.Itisimportantto
notethatonesettingappliestobothrollandpitchaxes;theyarenotindi
-
viduallyadjusted.
(DUALRATESMUSTBE100)
-Suggestedamountofbasecyclicpitch
*800size‒10degrees
*700size‒9degrees
*600-550size‒8degrees
*500size‒7degrees
*450andbelow-6degrees
Settingranges:0~100%Initialvalue:50%
(9) PIT. Rate: Rate adjustment
The[PIT.Rate]istheamountofcollectivepitchtravelallowed.Agood
startingrangeforSport,3DandF3Cis+/-10to+/-12degrees.
Settingranges:0~100Initialvalue:50%
(10) SWS. Ring
Thisparameterisusedtosetthetotalmaximumofcyclicthrowaswellas
limittheswashtraveltopreventbindingoftheswashplateservoswhen
thecontrolstickismovedtowardacorner(forexample,fullrightandfull
aftcyclic).
Settingranges:50~100%Initialvalue:130%
(11) AGy. Dir: Aileron (roll) Gyro direction
EGy. Dir: Elevator (pitch) Gyro direction
ThisparametercontrolswhichdirectiontheCGY(roll/pitchaxis)will
compensatewhenthehelicopterrolls(pitches).Pickthehelicopterup
androllthehelicoptertotheright.TheCGYshouldcompensatebyadd
-
ingleftcyclictotheswashplate.(Pickthehelicopterupandrotatethe
noseofthehelicopterdownward.TheCGYshouldcompensatebyadd
-
ingaftcyclictotheswashplate.)
IftheCGYcompensatesinthewrongdirection,thenitwillbenecessary
toreversethecompensationdirectionsetting.
WARNING
VerifythattheCGYcompensatesinthecorrectdirectionbefore
flight.Ifthecompensationdirectionisincorrectthemodelwillrollor
pitchuncontrollablyevenbeforeitleavestheground.
(13) STK. Dir ELE: Elevator operation
Loadthedirectionofelevatorintothegyro.
[Settingmethod]Touchthe"Up"buttontoenterthesettingmode.
"Sure?"Isdisplayed.Operatetheelevatorstickfullytotheup.Ifyou
touchthe[Yes]button,theoperationdirectionofelevatorismemorized.
(12) STK. Dir AIL: Aileron operation
LoadthedirectionofAileronintothegyro.
[Settingmethod]Touchthe"Right" buttontoenter thesettingmode.
"Sure?"Isdisplayed.OperatetheAileronstickfullytotheright.Ifyou
touchthe[Yes]button,theoperationdirectionofAileronismemorized.
Besuretosetthisaileronmotiondirectionandelevatormotiondirection
sothatF/Fmixing(EleCompandRud.F/Fmenu)workseffectively.Also,
pleaseperformthisoperationaftersettingthedirectionofoperation.
*ThecurrentconditionnumberofCGYisdisplayed.
*Thesettingwith"C#"displaycanbesetforeachcondi-
tion.
1.Usethe"C#"buttontoselecttheconditionnumber.
2.Next,adjustvalueoftheconditionselectedbythe
rate
button.
Forfunctionsthatcansetconditionsin
thismanual,mark
Cond
iswritten.
Cond
Cond
Cond
WARNING
VerifythattheCGYcompensatesinthecorrectdirectionbefore
flight.Ifthecompensationdirectionisincorrectthemodelwillrollor
pitchuncontrollablyevenbeforeitleavestheground.
