GyrosettingCGY770R
GovernorBasic
GovernorBasic
(6) Stick sw.: Stick switch
Thegovernorcanbeactivatedbythrottlestickposition.
[Settingmethod]Touchthe"StickSW"buttontoenterthesettingmode.
OperatethethrottlesticktothepositionwhereyouwanttoturnGover
-
norON.Touchthe“StickSW”buttonagain.“Sure?”Isdisplayed.Ifyou
touchthe[Yes]button,theONpositionismemorized.Thisstickswitch
functionisalwaysenabledwhenthenext"ON/OFFsw"is"INH"orthe
"GovernorON/OFFswitchisnotsetbyS.BUSsetting.
Whengovernoristurnedonandoffbytransmitterthrottlestick
 Thedataissetsothatthegovernorcanbe
turnedonandoffwiththetransmitterthrottle
stickposition.Thefollowingdescribesthis
operation.
•Throttlestickoversetpointandmorethan
60%ofsetrotationspeed.

ON
*Thisisthesettingvalueof"Gov.On.Revo:
GovernorONrevolutionsetting".
•ThrottlestickheldatthesetpointormoreRe
-
mains.

ON
•Throttlestickpositionisbelowthesetpoint
selected.


OFF
Whenidleup
•Whenthethrottlecurveissetatidleup,andwhenthethrottleoutputisoverthe
setvalue(initialvalue:30%),thegovernorwillalwaysandremainONevenifthe
stickisloweredtothebottom.
(OFFatslowside)
Setpointorless
0%
100%
(Governoroperating
point)
Setspeed
Thestickisat,orbe
-
yondthesetpointand
is60%oftherotation
speedvalueofthe
governor.
Whenyouactivatethe switch,thedirectionsettingoftheswitchisdis-
played.SelecttheswitchON/OFFdirection(Normal/Reverse).
Whenturningon/offgovernorwithswitch
 SelecttheON/OFFswitchchannelwith"GOVswchannel"on"SBUSBASIC"menu.
 SettingtheswitchtotheONpositionturnson,orenablesthegovernor.Thefol
-
lowingdescribesthisoperation.
•Switchsettoonpositionandenginerunningat60%or
moreofsetspeed
ON
•Throttlesticksettomaximumslowposition
ON
•Switchsettooffposition


OFF
212))VZ*RYHUQRURQRৼVZLWFK
Thisparameterallowstheusertoturnthegovernoronoroffviaaswitch
onthetransmitter.ChooseINHifyoudonotwanttouseit.
Governorcanbeturned
onandoffbyaswitch.
WhenBatteryFailSafeisenabled,itemsforsettingthethrottleservoposi-
tionaredisplayed.Thesettingmethodisthesameas"Sticksw",soplease
refertothissectionofthemanualforinformationonsettingthisfunction.
(8) BAT F/S: Battery fail safe
Whenthereceiverbatteryvoltagebecomesequaltoorlessthan"BFS.
Volt"setinthe"GovernorExpert"menu,thebatteryfailsafefunctionis
activated,thegovernorfunctionisturnedOFF,andthethrottleservo
movestothesetposition.
Ifthebatteryvoltageislowerthanthesetvoltageofthe"BatteryF/S"
forabout3seconds,theGx(gyro)LEDoftheCGYsolidredlight.When
"BatteryF/S"issetto"ACT"in"GOVBASIC",theservoisfixedtothe
throttlepositionsetby"BatteryF/S".Whenthe throttlestickissetto
theslowestposition,the"BatteryF/S"functionistemporarilycanceled.
However,after30seconds,the"BatteryF/S"functionisactivatedagain
andtheservoislocked.Whenthe"BatteryF/S"operates,quicklyland
-
ingandstoppingthehelicopter,pleasechargethebattery.
WARNING
 WhenusingtheCGYforthefirsttime,orwhenmakingchangesinthe
throwofaservoanditslinkage,alwaysperformthelimitsettingopera
-
tion.
WARNING
 WhenusingtheCGYforthefirsttime,orwhenmakingchangesinthe
throwofaservoanditslinkage,alwaysperformthelimitsettingopera
-
tion.
(9) Lim. set: Servo limit point setting
Servolimitpointsettingdefinestheoveralltravelrangeforthethrottle
servo.Itisfundamentalforgovernoroperationandmustbesetpriorto
otherfunctions.Servolimitsmustalsoberesetwhenthethrottlelinkage
ortrimarechanged.
Howtosettheservolimitpoint:
Touchthe“Lim.SetId”buttontoenterthesettingmode.
Setthetransmit-
terʼsthrottlesticktotheidleposition.
Touchthe“Lim.SetId”buttonagain. 
ThelimitofidlewillbesavedtotheCGY. Thecursorwillmoveto"Lim.Set
Hi".Setthesticktothefullhigh position.
Touchthe“Lim.Set Hi”button
again.
 ThelimitofhighwillbesavedtotheCGY. Ifthesettingdataisnot
normal(servooperationamountis50%orless),"Err"isdisplayed.Inthis
case,checkthetransmittersettingandrepeatthisprocedureonceagain.
(10) Limit Test: Check the set limit point
Checkthesetlimitpoint.Press"Idle"or"High"tomovetheservotoeach
limitpoint.Press“End”toendthetest.
