Stick mode selection and J1-J4 sticks calibration
Thestickissetat
neutral
Fullrightand
fullbottom
Fullleftand
fulltop
ūŒźŃƖƈƗƗƌƑƊ
Usually, this H/W setting is unnecessary.
Please perform this calibration only if a change at
the center of a stick should arise after prolonged use.
2. Choose the stick to calibrate right and left.
3. The stick is set at neutral and the [Set neutral]
button is tapped.
ūƒƚŃƗƒŃŦƄƏƌƅƕƄƗƈŃ
1. Tap the "Calibration" button.
3OHDVHGRQRWSUHVVWKHVWLFNWRR¿UPO\LQDQ\GLUHFWLRQZKHQ
doing the calibration.
*Check after calibration to make sure that neutral is 0%, the
bottom right side is +100%, and the top left side is -100%.
●
Tap the [Calibration] button in the System menu to
call the setup screen shown below.
●
Return to
System menu
4. The stick is held at full right and full bottom
(diagonal). The [Set endpoint] button is tapped.
5. The stick is held at full left and full top (diagonal).
The [Set endpoint] button is tapped.
Tapped
Tapped
Tapped
ŃŶƗƌƆƎŃƐƒƇƈ
Mode 1-4 can be
chosen.
But, it isn't changed
until data is reset.
AIL
THR
RUD
ELE
MODE1
AIL
ELE
RUD
THR
MODE2
AIL
THR
RUD
ELE
MODE3
AIL
ELE
RUD
THR
MODE4
WhensettoON,youcan
selecttheswitchandON/
OFFdirectionbyoperating
thedesiredswitchwhen
selectingtheswitchfor
eachfunction.
ON →Aconfirmationscreenwillappear
whenthepoweristurnedOFF.
OFF→Thepowerturnsoffimmediately.
