75
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
●
Tap the [Throttle cut] button in the Linkage menu to call
the setup screen shown below.
ŷƋƕƒƗƗƏƈŃƆƘƗ
Stops the engine safely and easily.
Throttle cut provides an easy way to stop the
HQJLQHE\ÀLSSLQJDVZLWFKZLWKWKHWKURWWOHVWLFNDW
idle. The action is not functional at high throttle to
avoid accidental dead sticks. The switch’s location
and direction must be chosen, as it defaults to "
−
−"
.
ŷƋƕƒƗƗƏƈŃƆƘƗŃƖƈƗƗƌƑƊŃƓƕƒƆƈƇƘƕƈ
1. Tap the "INH" button.
2. Throttle cut function switch setting:
Tap the "--" button to call the <Hardware
select> screen, and then select the switch
and its ON direction.
(For a detailed description of the selection
method, see [Switch selection method] at
the back of this manual.)
3. Throttle cut position setting:
Tap the cut position button. Value input
buttons appear on the screen.
Use these buttons to adjust the cut
position rate.
ŏ,QLWLDOYDOXH
ŏ$GMXVWPHQWUDQJH
（
LOW
）
a
（
Middle
）
*With throttle stick at idle, adjust the rate until the engine
FRQVLVWHQWO\VKXWVR൵
To exit the setting, tap the [Throttle cut]
button.
Theyellowlineisthe
cutposition.Whenthe
cutswitchisON,the
throttlewillmoveto
thisposition.
Tappingthiswillpullupthe
hardwareselectionscreen.
Selectthethrottlecutswitchand
ON-OFFdirection.
Thisindicatesthethrottlestick'scurrent
position.Throttlecutwillonlyfunctionwhen
thethrottlestickismorethan1/3rdintothe
slowthrottlerange.
Tappingthiswillchange
INHtoeitherOFForON
andactivated.
●
Return to Linkage
menu
Thisisthethrottlecut
position.Tappingthiswill
displayvalueinputbuttons
on-screen.Settheengine
stopposition.
