FUTABA T26SZ - Page 77

77
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
Themarkerrepresentsthe
stick'sposition.
Themovementrange
displayshowscontrol
inputforelevatorand
ailerondirection.
Settingthefunctionto
"ACT"willdisplaythe
swashringand[Rate]
percentage.
●
Tap the [Swash ring] button in the Linkage menu to call
the setup screen shown below.
ŶƚƄƖƋŃƕƌƑƊ
/LPLWVWKHVZDVKWUDYHOZLWKLQDÀ[HGUDQJHWRSUHYHQWOLQNDJHGDPDJH
(Helicopter only)
This function limits the travel of the swash plate to
prevent linkage damage as the aileron and elevator
operation is used. It is useful for 3D heli setting.
ŶƚƄƖƋŃƕƌƑƊŃƖƈƗƗƌƑƊŃƓƕƒƆƈƇƘƕƈ
1. Push the Swash ring button on the linkage menu.
2. Push ACT/INH button to activate.
*The movement area monitor shows the current aileron and
elevator values and limit ranges by the yellow circle.
3. Adjust the rate to the maximum amount of swash
plate decline.
*The swash movement is limited within the circle.
 $GMXVWPHQWUDQJH
●
Return to Linkage
menu
