Commonfunction
ThissettingwillsoundanalarmwhentheEXT-voltagedropsdangerouslylow.VIB(vibration)that
vibratesthetransmitteratthesametimecanalsobeset.
Method
①Select"EXT-VOLT"fromthe
telemetryscreenwiththeJogkey.
②Openthesettingscreenby
pressingtheJogkey.
① IntheEXT-VOLTscreenstate,select
(ALARM)fromthemenuwiththe
Jogkey.
② Selectthe"ACT"bypressing
the+keyor‒key.
①IntheEXT-VOLTscreenstate,
select(LIMIT)fromthemenuwith
theJogkey.
②Selectthe voltageby
pressingthe+keyor‒
key.
Selectionrange：
0.0V 〜 70.0V
● Whenyouwanttoset5.0V,pressthe
+keyand‒keysimultaneously.
① IntheEXT-VOLTscreenstate,select
(VIB)fromthemenuwiththeJog
key.
②Selectthe"TYP1 〜 TYP3"by
pressingthe+keyor‒key.
Callingthesettingscreen
Alarmset
Alarmvoltageset
Vibrationset
● EXT-Voltagealarmsetup
＋ −
or
＋ −
or
＋ −
or
TYPE1
TYPE2
TYPE3
"VIB"types
Ifthefollowingtypesareselected,the
transmitterwillvibrateduringthewarning.
DN(down)showsthanan
alarmisgeneratedwhen
thevoltagedropsbelow
thesetvoltage.
