FUTABA T8J-2.4G - Servo Reversing (REVERSE); Reversing Servo Direction

35
Servo reversing (
REVERSE
): changes the direction an individual servo responds to a CONTROL STICK motion.
)RU&&30KHOLFRSWHUVEHVXUHWRUHDGWKHVHFWLRQRQ
SWASH AFR
(p. 75) before reversing any servos.
With the exception of CCPM helicopters, always complete your servo reversing prior to any other programming.
When using
ACRO
functions that control multiple servos, such as
FLAPERON
or
V-TAIL
, it may be confusing to determine
whether the servo needs to be reversed or a setting in the function needs to
be reversed. Refer to the instructions for each specialized function for further
details.
Always check servo direction prior to every flight as an additional
SUHFDXWLRQWRFRQ¿UPSURSHUPRGHOPHPRU\KRRNXSVDQGUDGLRIXQFWLRQ
NOTE:
THR-REV
is a special function that reverses the entire throttle control, including moving the trim functionality to
WKH6WLFN¶VXSSHUKDOI7RXVH
THR-REV
: see p.92. This change affects all models in the radio.
GOAL of EXAMPLE: STEPS: INPUTS:
Reverse the direction of the elevator
servo.
Open
REVERSE
function.
for 1 second.
to
REVERSE
.
Choose proper channel and set
direction. (Ex:
ELE REV
)
to
ELE
.
for 1 second.
&RQ¿UP\RXUFKDQJH
Sure?
displays.
Close.
Where next? Adjust servo travel with
END POINT
: see p. 36.
Set up dual/triple rates and exponential(
D/R
,
EXP
): see p. 39.
6HWXSÀLJKWWLPHUVVHHS
Set up trainer functions: see p. 44.
[T8Jofthetransmitsside]
1.ThedataofamodeltosendiscalledbyMDL-SEL.
2.MODEofMDL-TRANSissetto“TRANSFER” .
3.“Execute” .
[T8Jofthereceivesside]
*Itreceivesfor10seconds.
1.TheclearmodeliscalledbyMDL-SEL.
2.MODEofMDL-TRANSissetto“RECEIVE” .
3.“Execute” .
MDL-TRANS
