Note:
After switching on, the CF-200 will automatically detect whether DMX 512 data is received or not. If the data
is received, the control LED flashes. If there is no data received at the DMX-input, the control LED lights up
permanently.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the CF-200.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
It’s necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.
DMX-protocol
Control channel 1 - Rotation
DMX-value Feature
0-19 No rotation
20-135 Rotation clockwise
136-139 No rotation
140-255 Rotation anti-clockwise
Control channel 2 - free
Control channel 3 - Colour-wheel
Linear colour change following the movement of the slider. In this way you can stop the colour-wheel in any
position.
DMX-value Feature
0-10 White
11-21 Magenta
22-32 Yellow
33-43 Dark blue
44-54 Light green
55-65 Pink
66-76 Purple blue
77-87 Dark orange
88-98 Pale yellow
99-109 Light blue
110-120 Light orange
121-127 Dark green
128-191 Forwards rainbow effect with increasing speed
192-255 Backwards rainbow effect with increasing speed
Control channel 4 – Gobos, Reset, Strobe
DMX-value Feature
0-7 Closed
8-15 Open
16-23 Gobo 1
24-31 Gobo 2
32-39 Gobo 3
40-47 Gobo 4
48-55 Gobo 5
56-63 Gobo 6
64-71 Gobo 7
72-79 Gobo 8
80-87 Gobo 9
88-95 Gobo 10
96-103 Gobo 11
