37
DANGER OF FIRE!
When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
CAUTION!
Use 2 appropriate clamps to rig the fixture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is fixed properly! Ensure that
the structure (truss) to which you are attaching the fixtures is secure.
The Moving-Head can be placed directly on
the stage floor or rigged in any orientation on a
truss without altering its operation characte-
ristics (see the drawing).
The fixture’s base enables to be mounted in
two ways. Use the clamps with screws M10 or
M8 - check the base bottom.
For overhead use, always install a safety-rope
that can hold at least 10 times the weight of the
fixture. You must only use safety-ropes with
screw-on carabines. Pull the safety-rope
through the eye bolt on the bottom of the base
and over the trussing system etc. Insert the
end in the carabine and tighten the fixation
screw.
Connection with the mains
Connect the device to the mains with the power-plug.
Clam
